RECYCLING

1/2

Mechanical Grapple

Ideal in lifting, transport and loading operations in recycling centers, waste loading/unloading, demolition work, scrap handling and rocks.

15 Models
Weights: 95 - 11,000 kg
Excavator Weight: 1.2 - 170 T
Openings:  1000 - 5000 mm
Rotation: No

5-tooth configuration, 2 on the front and 3 on the back

Totally built in HARDOX 400

No hydraulic system required because it exploits the thrust force of the piston of the excavator's penetrating arm

Connecting rod and support to be welded supplied with the grapple

Support with 3 holes: 3 positions = 3 different jaws opening

Greasing points on the fulcrum pins
